700H
Minimum energy, maximum performance
The 700H snow cannon combines high efficiency, energy efficiency and reliability, designed for modern ski resorts and recreational trails. With a maximum water intake of up to 510 l/min and low energy consumption (14.3 kW), this model achieves an impressive output of 88 m³ of snow per hour – ensuring the stability of the winter season even in adverse weather conditions.
Key features of the 700H cannon:
Super-efficient nucleation technology
High snow quality and easy operation
The system of 96 water nozzles and 6 nucleation nozzles makes it possible to achieve high snow density (330-870 kg/m³) and up to 7 degrees of snow quality. Cleaning and maintenance of components (including the mesh filter) are quick and intuitive
Energy-efficient water design
The hybrid water unit uses the pressure and thermal energy of water to control the valves, reducing energy consumption and making the whole process more eco-friendly
Durability and precision with TwinC® nozzles
Highly abrasion-resistant ceramic inserts guarantee longevity, optimal spray angle and ideal droplet size
Quiet operation, full functionality
Optimized fan channel geometry and modern impeller blade design reduce noise and increase airflow efficiency. The cannon rotates 360° and offers automatic oscillation (15°-120°)
85m3/h
Performance
Max snow production
330-870 kg/m3
High quality snow
Range of density of snow produced
510 l/min
Effectiveness
Max. water intake
7
Precision
Number of degrees of snow quality
14.3 kW
Save
Nominal power consumption
360°
Functionality
Range of rotation
Number of water sections
5
Number of nucleation sections
1
Number of water jets
96
Number of nucleation nozzles
6
Working pressure of water
8-40 bar
Water intake for
510 l/min
Max snow production
88m3/h
Weight
Cannon without chassis
600 kg
Cannon on a technological base
620 kg
Foot chassis complete
160 kg
Wheeled chassis
270 kg
Other
Fan speed
1450 rpm
Range of density of snow produced
330-870 g/l
Number of degrees of snow quality
7
Adjustment range of the tube angle
0°-45°
Range of rotation
360°
Automatic oscillation with angle adjustment range
15°-120°
Electrical
Nominal power consumption
14.3 kW
Water ring heating
1.8 kW
Oil-free compressor
1.5 kW
Fan motor
11 kW
LED work light, 12/24 volts, 30 watts
Warning lamp
Oil-free compressor 1,5 kW
Angled swivel connector with horizontal inlet with 2″ female camlock
Rubber water hose of the mobile cannon, length 1.9 m
Removable operator panel integrated into the cannon
Power cable 5×6 mm2, length 22 m
Hydrant drive cable, length 22 m
Operator panel cable, 1.8 m long
SUPERWIRE or SUPERWAVE communication
DV7 hydrant drive
DV7 drive mount for dedicated hydrant
SNOWFLEX hose with camlock ends 2″, 20 m
Foot or wheeled chassis
